iFlight BLITZ Whoop F7 AIO
Part number
Catalog only
Normalized against the v5 schema baseline.
Product specifications
Sd Card
No
Mcu Chip
stm32f745
Osd Type
none
Barometer
none
Dual Gyro
No
Mcu Family
f7
Uart Count
0
Built In Rx
No
Built In VTX
No
ESC Firmware
blheli_s
I2c Available
No
Has Inverter Pad
No
ESC Channel Count
4
Max Input Voltage
25.2
Min Input Voltage
7.4
Continuous Current A
55
Compatibility & Build Notes
Build note 01
55A per-channel current handling is a fast way to sanity-check the motor and prop load this board can support.
Build note 02
Power input is published for 7.4V to 25.2V, so make sure your cell count and battery plan stay inside that band.
Build note 03
0 available UARTs gives you a rough budget for receiver, GPS, VTX control, and other serial accessories.
Build note 04
4 ESC channels indicate the board is aimed at a standard multirotor layout unless your build plan says otherwise.
